Basic Info.
Model NO.
SNLS-3000W 2560
Structure Type
Gantry Type
Laser Classification
High- Performance Fber Lasers
Laser Technology
Laser Vapor Cutting
Automation
Automatic
Certification
RoHS, ISO 9001:2000, CE
Condition
New
Waterproof Rating
Ipx-5
Pigment
Can Be Customized
Foundry
Can Contract
Customization
Available
Overseas Sales Agent
We Can Talk
Transport Package
Plastic Film or a Wooden Box
Specification
3*1.5/4*1.5/6*1.5/4*2/6*2(m)
Trademark
Sinuo
Origin
China Nanjing
Production Capacity
2000/Year
Product Description
Nanjing Snow Intelligent Equipment Co., Ltd. is a company focusing on the research and development, manufacturing and sales of machine tools and machine tool accessories. Our company is a famous mechanical equipment manufacturing company in Nanjing, which is a high-tech intelligent equipment manufacturing company independent by an old enterprise 28 years ago in 2023. The headquarters is located in Nanjing City, Jiangsu Province, China. As an advanced technology, experienced enterprises, Nanjing Snow Intelligent Equipment Co., Ltd. is committed to providing customers with the most advanced, the highest quality machinery and equipment. The company specializes in the production of optical fiber laser cutting machine and other series of dozens of products, widely serving in sheet metal manufacturing, auto parts, hardware tools, precision instruments, agricultural machinery and many other industries, the products sell well at home and abroad. Our main products include CNC shear machine, CNC bending machine, fiber laser cutting machine, punch, CNC package groove machine, joint cutting machine, slaughtering equipment and its accessories, etc. Our CNC board shear machine is based on advanced CNC technology and cutting theory developed, and has the characteristics of high degree, high efficiency and good stability. CNC bending machine can be bent according to the needs of customers, and can ensure the quality and precision of products. Fiber laser cutting machine uses fiber laser technology, can achieve high speed, high precision cutting. The unch can be punching, punching, convex and other processing, widely used in metal processing industry. CNC package groove machine is suitable for various types of box girder, groove steel and other groove processing, has the characteristics of high efficiency and high precision. Joint cutting machine is a multi-functional equipment integrating the functions of punch machine and cutting machine, which can meet various processing needs of customers. Slaughter equipment is our new line of products and we are committed to providing advanced equipment and solutions for the meat processing industry. In the market competition, Nanjing Sinuo Intelligent Equipment Co., Ltd. always adhere to the customer demand as the guidance, constantly innovate and improve products, to provide customers with customized solutions. We have a skilled, professional research and development team, as well as an efficient, enthusiastic sales team. Our products are exported to both at home and abroad, and are deeply recognized and trusted by our customers.
Nanjing Sinuo Intelligent Equipment Co., Ltd. will continue to be committed to technological innovation and product quality improvement, and continue to meet customer needs, to create greater value for customers. Company adhering to adhere to the "market-oriented, take customers as the center, with quality as the core, to service for guarantee" business philosophy, adhering to the "talent, leading science and technology, honest and trustworthy, innovation" the enterprise purpose, in the rapid development of laser application technology today, as a mature pragmatic laser equipment manufacturing enterprises, Nanjing snow have strength, ability, have the responsibility for the majority of new and old customers to provide technology more advanced, higher cost-effective laser equipment. We look forward to working together with you for common development.
| Sheet metal material | Laser power | ||||||||
| 1000W | 1500W | 2000W | 3000W | 4000W | 6000W | 8000W | 12000W | 20000W | |
| Carbon steel | 1-10mm | 1-14mm | 1-18mm | 1-22mm | 1-22mm | 1-22mm | 1-22mm | 1-30mm | 1-55mm |
| Stainless steel | 6mm | 8mm | 10mm | 10mm | 14mm | 20mm | 25mm | 40mm | 45mm |
| Aluminium alloy | 3mm | 6mm | 8mm | 8mm | 10mm | 16mm | 18mm | 22mm | 25mm |
| Brass | 3mm | 6mm | 8mm | 8mm | 10mm | 16mm | 18mm | 22mm | 25mm |
| Model | SNL-3015 | SNL-4015 | SNL-4020 | SNL-6020 | SNL-6025 | SNL-8025 | SNL-8030 |
| Processing range | 3000*1500mm | 4000*1500mm | 4000*2000nn | 6000*2000mm | 6000*2500mm | 8000*2500mm | 8000*3000mm |
| X-axis travel | 1500mm | 1500mm | 2000mm | 2000mm | 2500mm | 2500mm | 3000mm |
| Y-axis travel | 3000mm | 4000mm | 4000mm | 6000mm | 6000mm | 8000mm | 8000mm |
| Z-axis travel | 140mm | 140mm | 140mm | 140mm | 140mm | 140mm | 145mm |
| X/Y-axis positioning accuracy | <=.0.032mm/min | <=.0.032mm/min | <=.0.032mm/min | <=.0.032mm/min | <=.0.032mm/min | <=.0.032mm/min | <=.0.032mm/min |
| X/Y-axis repeated positioning accuracy | <=.0.02mm/min | <=.0.02mm/min | <=.0.02mm/min | <=.0.02mm/min | <=.0.02mm/min | <=.0.02mm/min | <=.0.02mm/min |
| maximum positioning speed | 120m/min | 120m/min | 120m/min | 120m/min | 120m/min | 120m/min | 120m/min |
| Laser power | 1000W/1500w/2000w/3000w/4000w/6000w/8000w/12000w/20000w/3oooow | ||||||
- sample displayMain configuration of equipment
| project | name | quantity | Origin and manufacturers |
| laser | 1500W, fiber laser | A set | Shanghai FEIBO /Machine USA GW <optional> |
| Cut the head | Special laser-cutting head | A set | JIA QIANG RAYTOOLS |
| machine bed host machine | Machine tool bed body | A | independent research and development |
| XY axis precision rack | A set | Taiwan YYC/KH | |
| Precision reducer | A set | Japan new treasure | |
| Servo motor and drive | Seven sets | Japan new treasure | |
| Precision guide rail | A set | Taiwan HIWIN | |
| Control cabinet electrical | A set | Schneider of France | |
| Gas valve system | A set | Japan SMC | |
| Pneumatic components | A set | Japan SMC | |
| CNC and software system | numerical control system | A set | Shanghai BAI CHU |
| standard accessory | Precision cold water unit | A set | Wuhan HANLI |
List of fiber laser cutter configuration
| name | picture | Brand and origin | capability |
| laser | FEIBO (Shanghai, China) | . Excellent beam quality (BPP) .BPP with constant BPP in the full power range .The long focal length is still available to obtain very small spots .Electric light conversion efficiency> 30% .Maintenance-free operation .Modular design, "plug and play" shape is compact, easy to install .The pump source service life is> 100,000 hours .Integrated light-optical coupling, or optical lock | |
| laser head | Swiss JIA QIANG RAYTOOLS | .. Auto-zoom .Non-contact sensing device .Automatically adjust the optimal focal length, Ensure the best cutting effect of the whole board | |
| numerical control system | BAI CHN(Shanghai, China) | . Set file reading, design, output and processing control as one.Ø .Provide rich laser cutting, process parameters, flexible layout and knife editing ability, the introduction of lead, bridging, The common side spot compensation, curve smoothing, segmentation, merging, automatic differentiation of internal and external modes and other functions.Ø .Support domestic and foreign fiber lasers, provide with speed PWM real-time power adjustment, gradual perforation anti-burst hole and other special processes. | |
| linear guide rail | Silver HIWIN (Taiwan, China) | . High design accuracy, easy installation; .High hardness, strong overload capacity; .Low noise and smooth movement | |
| host | Tying Technology | . The CPU is G1820,4G memory, 120G solid state drive | |
| Gear teeth | YYC / KH (Taiwan) | .High hardness; .6H accuracy;Ø .Easy to install. | |
| servo motor | Panasonic Panasonic (Japan) | . High-precision servo motor; .Can control the cutting speed and position; .Smooth operation, low speed, no vibration phenomenon; .Better carrying capacity | |
| decelerator | ØNew treasure(Japan) | . High precision, high rigidity, and .High torque. High-load capacity .No grease leakage .Convenient maintenance | |
| Proportion er | SMC(Japan) | . Unlimited adjustment of the pressure and speed | |
| electrical apparatus element | Schneider Schneider (France) | .Global leading brand in the electrical field .Super stability | |
| cooling-water machine | ØSpecial Area S & A (Guangzhou, China) Hanoi (Wuhan, China) | . Special laser machine; .A variety of protection functions, passive, alarm terminal and remote control, terminal, easy to realize CNC centralized control and monitoring; .System components use international known, famous brand, to ensure the quality of equipment, good reliability | |
| cable conductor | Delores (Germany) | . Product performance complies with the European CE standard | |
Ø Oil system | Guangdong, China | . Automatic timing oil supply; after enabling, after a period of time, gear, rack and guide rail need to inject lubricating oil for maintenance to ensure smooth operation of the machine with high precision. | |
| lathe bed | independent research and development | . Steel plate welding .drawing temper | |
| crossbeam | independent research and development | . Steel plate welding .drawing temper | |
| The fuselage processing | Qiqihar | . Large gantry milling-fuselage equipment processing | |
| Ø Sponge gear | independent research and development | . Lubrication dust-proof | |
| Dust skating table | Auriga YOUYUIA (China | . high-accuracy | |
| Oil tank and press block | independent research and development | . Increase stability |
- Overall parameter table of the equipment
| Processing format and working scope | Performance index parameters |
| model | SNL-1500W 6025 |
| X axis itinerary | 200mm |
| Cut slit width | 0.1-0.2mm |
| Z axis itinerary | 250mm |
| Y axis itinerary | 6000mm |
| Maximum one-time processing length | 6000mm |
| X, and the Y-axis positioning accuracy | ±0.03mm\1000mm (6000mm±0.05mm) |
| X, Y-axis repeat positioning accuracy | ±0.03mm |
| X-axis empty running speed | ≤60m/min |
| The material length | 6000mm |
| Machine tool operating temperature | 0ºC-40ºC |
Equipment work and environmental requirements
order number | content |
1 | Power supply requirements: (stable power supply is recommended) Rated output voltage: 380V / 50Hz Voltage stability: + 5% |
| 2 | Air flow rate: 1 l / min Compressed air supply device (recommended gas storage tank, cold dryer) Volume: 1 m3 Rated pressure: 1.5 Mia |
| auxiliary gas | auxiliary gas |
| Cut auxiliary gas | purity requirement |
| oxygen(O2) | ≥99.95 % |
| nitrogen (N2) | ≥99.99 % |
Description of the equipment installation and use environment:
1, the fiber laser environment requirements: the temperature in 15-35ºC, the relative humidity is lower than 85%.
2. On-site power distribution cabinet: 380V, 50Hz, three-phase four-wire, with short-circuit protection, etc.
3, the equipment shall be installed with special grounding, and its grounding resistance shall not exceed 4
.4. Provide the necessary lifting equipment and personnel
