High Efficiency Oil Cold Press Machine 120~150 Ton Per Day Automatic Hydraulic Sesame Oil Making Machine

Get high-quality sesame oil with our automatic hydraulic oil making machine. Our factory offers a 120~150 ton per day cold press machine for high efficiency production.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
Various
Condition
New
Customized
Customized
Function
Making Edible Oil
Warranty
12 Months and Long Term Technical Support
Raw Materia
Peanut, Rapeseed, Cotton Seed and etc.
Brand Name
Sinoder
Transport Package
in Wooden Packaging, According to The Customer Re
Specification
Various
Trademark
sinoder
Origin
China
HS Code
8462919000
Production Capacity
98%-100%, 100 Pieces Per Month

Product Description

Product description
High Efficiency Oil Cold Press Machine 120~150 ton Per Day  Automatic Hydraulic Sesame Oil Making Machine
Our Sinoder Indutech Machinery Company supply the complete set of Cooking oil
production line machinery including sunflower oil production line, palm oil production line, soya bean oil production line, peanut oil production line, cotton seeds oil production line, maize corn germ oil production line, clamelia oil production line, rapeseeds oil production line, canola oil production line, coconut cropra oil production line, shea oil production line, groundnuts oil line, sesame oil production line,black seeds oil production line, jatropha seeds oil production line,moringa seeds oil production line and other vegetables oil processing machines.

High Efficiency Oil Cold Press Machine 120~150 Ton Per Day Automatic Hydraulic Sesame Oil Making Machine



Sinoder Brand 6YZH Series Hydraulic Oil Press Machine Parameters:

Type QYZ-230 QYZ-410 QYZ-460-1 QYZ-460-2 QYZ-460-3 QYZ-500
Working pressure 50 Mpa 45Mpa 40Mpa 40Mpa 40Mpa 40Mpa
Pushing force of working 120tons 120tons 150tons 210tons 150tons 300tons
Inner diameter of pressing barrel 230mm 410mm 460mm 460mm 460mm 500mm
Working stroke of piston 500mm 500mm 500mm 500mm 700mm 700mm
Capacity/Average performance 45kg/h 80kg/h 110kg/h 110kg/h 150kg/h 200kg/h
Main motor 1.5kw 1.5kw 2.2kw 3kw 3kw 4kw
Motor of heating 4kw 4kw 4kw 4kw 4kw 4kw
Oil cylinder of pre-pressing 10Mpa 10Mpa 10Mpa 10Mpa 10Mpa 10Mpa
Weight 1300kg 1500kg 1800kg 1800kg 2300kg 2800kg
High Efficiency Oil Cold Press Machine 120~150 Ton Per Day Automatic Hydraulic Sesame Oil Making Machine
Applictions

Edible oil press machine, which is also called oil expeller, oil extraction machine or oil mill, It can be used for various raw materials, such as soybeans, peanuts, cotton seeds, rape seeds, sesame seeds, sunflower seeds, canola seeds, coconut seeds, tea seeds, palm seeds and jatropha seeds.
High Efficiency Oil Cold Press Machine 120~150 Ton Per Day Automatic Hydraulic Sesame Oil Making Machine

We meet the demands of virtually every application in the vegetable oil processing industries. With premium quality oil mill machinery, oil extraction machines and professional oil processing systems & oil refining technologies in the field of vegetable oil extraction and refineries, you can depend on our equipment and expertise to help you hulling, crushing, conditioning, flaking, cooking, extruding, expelling, extracting, degumming, neutralizing,dewaxing/fractionation.

We (our Sinoder Company) supply small scale oil press machines for home or village use, Hydraulic Oil Press Machine for small scale oil factory and home use, large scale production oil screw pressing line and oil refinery lines for commercial production factory use.

Sinoder  6YL Series Small Scale Oil Press Machines (for home or village family workshop use)
High Efficiency Oil Cold Press Machine 120~150 Ton Per Day Automatic Hydraulic Sesame Oil Making Machine


 Sinoder Brand 6YL Series Small Scale Oil Press Machines Parameters:

Model 6YL-60 6YL-80 6YL-100 6YL-120 6YL-160
Dia. Φ53mm Φ81mm φ101mm φ123mm φ160mm
Screw speed 64 r/min 47r/min 38r/min 35r/min 32r/min

Power
Motor 1.5-2.2kw 5.5kw 7.5kw 11kw 22kw
Vacuum pump 0.18kw(VP-1.5) 0.55kw 0.75kw 1.1kw 1.1kw
Heater 0.9kw 2.2kw 2.2kw 2.2kw 2.2kw
Capacity 4.-60kg/h 80-100kg/h 150-200kg/h 250-300kg/h 500-600kg/h
Weight 268kg 880kg 1250kg 1500kg 1800kg
Size(mm) 1020*720*798 1500*1200*1750 2000*1300*1850 2100*1300*1850 2300*1300*1950


Large scale screw Oil pressing Machine for commercial oil factory use:
High Efficiency Oil Cold Press Machine 120~150 Ton Per Day Automatic Hydraulic Sesame Oil Making Machine



Model Capacity Oil in cake Power Overall dimensions(L×W×H) N.W.
ZY24A 60-80 t/d 12-18 % 30+5.5+3.0 kw 2900×1850×3640 mm 5500 kg
ZX24A 15-20 t/d 7-9 % 30+5.5+3.0 kw 2900×1850×3640 mm 5500 kg
ZY28 120-150 t/d 16-20 % 75+11+4.0 kw 3740×1920×3843 mm 9160 kg
ZX28 40-60 t/d 7-9 % 55+11+4.0 kw 3740×1920×3843 mm 9160 kg
ZY32 220-260 t/d 16-20 % 110+11+5.5 kw 4100×2270×3850 mm 11000 kg
ZX32 90-100 t/d 8-10 % 90+11+5.5 kw 4100×2270×3850 mm 11000 kg


Complete Edible Oil Manufacturing Unit includes

♦   Cleaning process : Use vibration cleaning sieve and magnetic selector to get better cleaning effect.And This step is mainly to clean the big impurities ,like the stone, big dust , iron etc.

♦   Crushing Process: This Process is mainly to crush the peanut , as the peanut is big ,it is not easy to press .We must crush the peanut to 6-8 pieces,then we need to peel .The rate of peel is about 90%.

♦   Flaking Process : After crush and peel ,we need to flake the crushed sunflower , which make the cell wall of sunflower broken . And we flake the sunflower to 0.55 mm thickness .Then it is useful for the oil extracting..

♦   Cooking Process: After the flaker,we need to cook the flaked sunflower , control the moisture at 5-7% ,the temperature is 110-115degree.

♦   Oil-pressing : After all the pretreatment , pre- press the sunflower , the oil can be extracted about 76% .

♦   Primary Oil Filtering Process: after the oil pressing, the crude oil will be primary filtered and for store to tank or for next process of oil refinery.
Strong manufacturing ability

♦    We have a professional service staff, and timely communication with the user, so that each machine is a "hen"lay eggs to make money.

♦    Nearly one century's history of manufacturing machinery,has a very valuable experience in manufacturing and technology services. Ensure every machine perfect.

♦    SINODER is the leading manufacturer and supplier of small oil press machine. Through years of development, our products has been rated as the best and reliable oil making equipment in the world.

♦    Therefore, we have been awarded various quality authentication from government institutes and alibaba. What's more, our good service is also well received by customers around the world.
Packing and delivery

1.The normal package is wooden box. If export to european countries,the wooden box will be fumigated.Or as customers required.
2.Port: Qingdao,Shanghai,Tianjing.
3.Lead time: Within 5-25 working days after payment confirming.
